Description
Premium Marine Engineering
The vessel features a robust catamaran hull constructed from marine-grade aluminium alloy 5083 H321, renowned for its exceptional strength-to-weight ratio, corrosion resistance, and longevity in harsh maritime environments. The superstructure utilises aluminium alloys 5083 and 6061, ensuring structural integrity whilst maintaining optimal performance characteristics.
The catamaran configuration delivers superior stability, reduced rolling motion for passenger comfort, and excellent fuel efficiency compared to monohull designs. With an 18.20-metre length overall and 6.50-metre beam, the vessel provides generous deck space whilst maintaining manoeuvrability in coastal waters.
Design Compliance
Engineered to comply with AMSA National Standard for Commercial Vessels (NSCV) Parts C, D, and E, ensuring comprehensive regulatory alignment for Australian coastal operations.
Draft (Loaded)
Approx. 1.30 metres
Operational Capabilities
Passenger Capacity & Certification
The vessel is designed to safely accommodate 100 passengers plus a crew complement of 2-3 persons, as per the approved stability booklet. This capacity makes it ideal for high-volume tourist routes, island hopping services, and scheduled ferry operations.
Certified for Coastal navigation under AMSA regulations, the vessel is suitable for operations along protected coastlines and within designated coastal limits. The construction will be undertaken under survey to achieve full AMSA Certificate of Operation, ensuring complete regulatory compliance from day one.
Survey Compliance
Built under continuous survey supervision to meet all requirements for AMSA Certificate of Operation, providing operators with confidence in regulatory compliance and passenger safety standards.
Passenger Capacity
Maximum certified passengers
Crew Members
Operational complement
Draft (Loaded)
Approx. 1.30 metres
Operational Capabilities
Passenger Capacity & Certification
The vessel is designed to safely accommodate 100 passengers plus a crew complement of 2-3 persons, as per the approved stability booklet. This capacity makes it ideal for high-volume tourist routes, island hopping services, and scheduled ferry operations.
Certified for Coastal navigation under AMSA regulations, the vessel is suitable for operations along protected coastlines and within designated coastal limits. The construction will be undertaken under survey to achieve full AMSA Certificate of Operation, ensuring complete regulatory compliance from day one.
Survey Compliance
Built under continuous survey supervision to meet all requirements for AMSA Certificate of Operation, providing operators with confidence in regulatory compliance and passenger safety standards.
Passenger Capacity
Maximum certified passengers
Crew Members
Operational complement
Propulsion & Performance
Twin Diesel Engines
2 × Volvo Penta D8-550 (550 HP each) or equivalent premium marine diesel engines from Scania or Caterpillar, providing reliable, efficient power for all operational conditions.
Advanced Propulsion
Twin Disc MGX-5094SC gearboxes paired with 4-blade nibral bronze propellers engineered for reduced vibration, enhanced fuel efficiency, and smooth operation.
Impressive Speed Range
Maximum speed of approximately 25-28 knots at half load, with an economical cruising speed of 20-22 knots, optimising operational flexibility and fuel consumption.
Fuel Capacity & Range
With an approximate fuel capacity of 2,000 litres, the vessel provides excellent operational range for extended tourist routes and multi-destination itineraries. The efficient catamaran hull design and modern diesel engines deliver superior fuel economy compared to traditional monohull vessels, reducing operational costs whilst maintaining performance.
Total fuel capacity for extended operations
Draft (Loaded)
Approx. 1.30 metres
Operational Capabilities
Passenger Capacity & Certification
The vessel is designed to safely accommodate 100 passengers plus a crew complement of 2-3 persons, as per the approved stability booklet. This capacity makes it ideal for high-volume tourist routes, island hopping services, and scheduled ferry operations.
Certified for Coastal navigation under AMSA regulations, the vessel is suitable for operations along protected coastlines and within designated coastal limits. The construction will be undertaken under survey to achieve full AMSA Certificate of Operation, ensuring complete regulatory compliance from day one.
Survey Compliance
Built under continuous survey supervision to meet all requirements for AMSA Certificate of Operation, providing operators with confidence in regulatory compliance and passenger safety standards.
Passenger Capacity
Maximum certified passengers
Crew Members
Operational complement
Propulsion & Performance
Twin Diesel Engines
2 × Volvo Penta D8-550 (550 HP each) or equivalent premium marine diesel engines from Scania or Caterpillar, providing reliable, efficient power for all operational conditions.
Advanced Propulsion
Twin Disc MGX-5094SC gearboxes paired with 4-blade nibral bronze propellers engineered for reduced vibration, enhanced fuel efficiency, and smooth operation.
Impressive Speed Range
Maximum speed of approximately 25-28 knots at half load, with an economical cruising speed of 20-22 knots, optimising operational flexibility and fuel consumption.
Fuel Capacity & Range
With an approximate fuel capacity of 2,000 litres, the vessel provides excellent operational range for extended tourist routes and multi-destination itineraries. The efficient catamaran hull design and modern diesel engines deliver superior fuel economy compared to traditional monohull vessels, reducing operational costs whilst maintaining performance.
Total fuel capacity for extended operations
Passenger Accommodation
Dual-Deck Configuration for Maximum Versatility
The vessel features a sophisticated two-deck layout designed to provide diverse passenger experiences whilst maximising capacity and comfort. The enclosed main deck offers climate-controlled premium seating, whilst the upper deck provides an open-air tourist experience ideal for sightseeing and photography.
Main Deck – Premium Saloon
Spacious enclosed saloon with business-class sofa seating for 60 passengers arranged in a comfortable 2×2 configuration. Featuring panoramic windows for exceptional views, central aisle for easy movement, and forward luggage storage area. Climate-controlled environment with LED lighting throughout ensures passenger comfort in all weather conditions.
Upper Deck – Open-Air Experience
Open-air tourist seating for 40 passengers under a lightweight canopy providing protection from sun and rain. Robust, comfortable bench seating allows passengers to enjoy unobstructed coastal views and fresh sea air. Ideal for whale watching, scenic cruises, and photography opportunities.
Wheelhouse – Command Centre
Ergonomic helm station with full 360-degree visibility ensuring safe navigation in all conditions. Two pilot seats provide comfort during extended operations. Comprehensive navigation and communication suite supports professional vessel operation and crew efficiency.
Amenities & Equipment
Passenger Facilities
Marine Heads
Two separate marine toilets – one dedicated crew facility and one passenger toilet – ensuring convenience and hygiene for all onboard.
Galley Unit
Compact galley designed for simple beverage service, allowing crew to provide refreshments during journeys and enhancing passenger satisfaction.
Audio System
Professional PA system for safety announcements and tour narration, plus background music system for enhanced passenger ambiance.
LED Lighting
Energy-efficient LED lighting throughout all decks and spaces, providing excellent illumination whilst minimising power consumption.
Navigation & Communication Suite
Comprehensive electronics package ensuring safe navigation and regulatory compliance:
- VHF Radio – Marine communication
- GPS/Chart Plotter – Precision navigation
- Radar – Collision avoidance
- Echo Sounder – Depth monitoring
- Magnetic Compass – Backup navigation
- AIS (Class B) – Vessel tracking and identification
- Navigation Lights – Full compliance lighting suite
This comprehensive equipment package ensures vessels meet all AMSA requirements for coastal operations whilst providing captains with the tools necessary for safe, efficient passage-making.
Important Considerations
Quotation Scope & Exclusions
This quotation represents a comprehensive estimate based on current market conditions in Thailand. To ensure complete transparency and avoid misunderstandings, please carefully review the following assumptions and exclusions that apply to this proposal.
Pricing Validity & Fluctuations
This quotation is based on current material and labour costs in Thailand and is subject to change. Final pricing may be affected by fluctuations in raw material costs (particularly aluminium) and currency exchange rates between quotation and contract signing.
AMSA Compliance Coverage
The AMSA compliance fee of $85,000 covers engineering liaison, documentation preparation, and standard survey requirements. Any additional modifications required by the surveyor beyond standard specifications may incur supplementary costs.
Excluded Costs
This quotation specifically excludes: international shipping from Thailand to destination port, marine insurance during transit, import duties and taxes at the destination port, and any owner-supplied items or equipment.
Final Specifications
The final specification, including confirmed engine brand and model selection, equipment manufacturers, and interior finishing details, will be confirmed and documented prior to contract signing to ensure complete alignment with client requirements.
Your Trusted Maritime Partner
Excellence in Vessel Construction
UBI Marine brings decades of expertise in commercial vessel construction, with a proven track record of delivering high-quality, compliant vessels to operators throughout the Asia-Pacific region. Our commitment to engineering excellence, regulatory compliance, and customer satisfaction ensures your investment delivers reliable, profitable service for years to come.
We are confident that we can deliver a high-quality, compliant, and efficient vessel that will serve your business excellently and exceed your expectations for performance, comfort, and operational reliability.
We look forward to the opportunity to discuss this project with you in further detail and answer any questions you may have regarding specifications, construction timeline, or regulatory compliance.
For and on behalf of UBI Marine Co., Ltd.
