6m Aluminum Central Console Fishing Boat

Specification
Maximum Persons Capacity For Protected Waters – cl 2.2.2
Outboard Weight From Table 2.1
Max Persons
295 kg or actual weight if heavier
6
Note: This is a Capacity Calculation and may not meet the Stability Requirements of Section 5. An inclining test will be required.
Maximum Persons Capacity For Boats Over 6m and Open Waters Requirements –
Passenger Heeling Moment
Total Mass of Occupants
Max Internal Breadth
Heeling Moment, Hp
540 kg
2.1 m
1852 Nm
Wind Heeling Moment
Factor P
375 for Open Waters
Area bove Waterline
7.39 m2
Distance between Centers of Areas
0.91 m
Wind Heeling Moment, Hw
2532 Nm
Max Heeling Moment for Test
2532 Nm
Total Mass of Boat in Test Condition
1935 kg
GZ Arm in Test Condition
0.133 m
Angle of Heel From GZ Curve
10 deg
Allowable Heel Angle
14 deg
PASS
Loss of Freeboard <25% PASS AS 1799.1-2009 Floatation Foam Requirements The Australian Builders Plate Does Not Require a Buoyancy Statement For Vssels Over 6m Dry Mass of Hull & deck Mass of Hull And Deck Submerged 930 kg 750 kg 60 kg Mass of equip Aluminium Factor (Table B1) Foam Density Foam Weight 0.62 30 kg/m3 36.3 kg Ms (submerged mas) Engine Submerged mass Load Capacity Total Supported Mass Volume Foam Req'd for BASIC FLOATATION BUILDERS PLATE SUMMARY Max Power Max Engine Weight Max Persons Max Load 200 HP 275 kg 6=540 kg 874 kg AS1799.1-2009 A Buoyancy Statement is NOT Required Information Determined Refer Fig 5 in National Standard for the Australian Builders Plate for Recreational Boats 686 kg. 205 kg (table 2.1) 874 kg 979 kg 1.21 m3
